ZT20 Integrated DTH Drill Rig for Open Pit Use

Product Overview

The ZT20 Integrated DTH Drill Rig is a high-performance drilling solution specifically engineered for open-pit mining, quarrying, and large-scale construction projects. Combining advanced pneumatic technology with robust mechanical design, this rig delivers exceptional drilling efficiency and reliability in demanding surface operations. Its integrated structure simplifies transport, setup, and operation, making it an ideal choice for professionals seeking productivity and cost-effectiveness.

Technical Features

• DTH Hammer System: Equipped with a high-efficiency Down-the-Hole (DTH) hammer, the ZT20 ensures superior penetration rates and hole straightness even in hard rock formations.
• Integrated Design: The rig integrates the compressor, power pack, and control system into a single unit, reducing footprint and eliminating the need for auxiliary equipment.
• Powerful Drilling Capacity: Capable of drilling holes with diameters ranging from 90mm to 165mm and depths up to 30 meters, adaptable to various open-pit requirements.
• User-Friendly Control: Features an intuitive control panel with real-time monitoring of drilling parameters such as air pressure, rotation speed, and feed force.
• Durable Construction: Built with high-strength steel frames and corrosion-resistant components to withstand harsh outdoor environments and continuous operation.
• Mobility and Stability: Mounted on a tracked undercarriage with hydraulic leveling jacks, ensuring stable positioning on uneven terrain.

Application Scenarios

The ZT20 Integrated DTH Drill Rig is widely used in the following fields:

• Open-pit mining for copper, iron, gold, and other mineral deposits.
• Quarrying for granite, limestone, sandstone, and marble extraction.
• Infrastructure projects such as road construction, dam foundations, and tunnel pre-splitting.
• Blast hole drilling for civil engineering and demolition operations.

Key Advantages

• Enhanced Productivity: The integrated design reduces setup time by up to 40% compared to traditional separate-component rigs.
• Lower Operating Costs: Optimized air consumption and fuel efficiency minimize energy expenses, while durable parts extend service intervals.
• Improved Safety: Enclosed operator cabin with vibration damping, dust suppression system, and emergency stop functions ensures a secure working environment.
• Versatility: Compatible with various DTH hammers and bits, allowing customization for different rock types and drilling conditions.
• Easy Maintenance: Modular components and accessible service points simplify troubleshooting and reduce downtime.

With the ZT20 Integrated DTH Drill Rig, you can achieve faster drilling cycles, higher accuracy, and greater return on investment in your open-pit operations. Contact us today for a tailored solution.
