ZT10 Integrated DTH Drill Rig for Open Pit Use

Product Overview

The ZT10 Integrated DTH (Down-the-Hole) Drill Rig is a state-of-the-art, heavy-duty drilling solution specifically engineered for open pit mining, quarrying, and large-scale construction projects. Combining high efficiency, robust construction, and advanced hydraulic technology, the ZT10 delivers exceptional performance in challenging surface environments. Its integrated design streamlines operation, reduces setup time, and ensures reliable, continuous drilling in hard rock formations.

Technical Specifications & Features

• Drilling Method: DTH (Down-the-Hole) hammer drilling for superior penetration in hard and abrasive rock.
• Hole Diameter Range: 90 mm – 152 mm (3.5" – 6.0"), adaptable for various blasthole requirements.
• Maximum Drilling Depth: Up to 30 meters (98 feet) in a single pass, with optional rod handling for deeper holes.
• Engine Power: Tier 3/Stage V compliant diesel engine, delivering 180 kW (241 hp) for high torque and fuel efficiency.
• Compressor System: On-board, high-pressure rotary screw compressor (22 bar / 320 psi) for optimal hammer performance.
• Feed System: Heavy-duty chain feed with 8,000 kg (17,600 lbs) pullback force and 6,000 kg (13,200 lbs) feed force.
• Rotation System: High-torque rotary head with variable speed (0–120 rpm) and torque up to 4,500 Nm (3,320 ft-lbs).
• Control System: Advanced PLC-based control with touchscreen interface, real-time drilling parameter monitoring, and automated rod handling.
• Undercarriage: Heavy-duty tracked undercarriage with 500 mm (20") triple grouser shoes, providing excellent stability and traction on uneven terrain.
• Dust Collection: Integrated dry dust collector with high-efficiency cyclonic and cartridge filtration, meeting OSHA and EPA standards.

Application Scenarios

The ZT10 is ideally suited for a wide range of open pit operations, including:

• Open pit mining (coal, copper, gold, iron ore, etc.) for production blasthole drilling.
• Quarrying (limestone, granite, marble, sandstone) for bench drilling and fragmentation.
• Large-scale civil engineering projects (dam foundations, road cuts, tunnel portals).
• Geotechnical investigation and pre-split drilling for slope stability.
• Infrastructure development requiring deep, straight holes in hard rock.

Key Advantages

• High Penetration Rate: Advanced DTH hammer and high-pressure air system deliver up to 30% faster drilling compared to conventional rigs.
• Exceptional Reliability: Reinforced frame, heavy-duty components, and corrosion-resistant materials ensure long service life in harsh environments.
• Operator Comfort & Safety: Enclosed, air-conditioned cabin with ergonomic controls, noise insulation, and panoramic visibility. Safety features include emergency stops, fire suppression system, and automatic brake.
• Low Operating Costs: Fuel-efficient engine, reduced wear parts, and easy maintenance access minimize downtime and total cost of ownership.
• Environmental Compliance: Low-emission engine and high-efficiency dust collection system reduce environmental impact and meet stringent regulations.
• Versatility: Quick-change rod handling system and adjustable angle drilling (vertical to 30° inclination) for diverse blasthole patterns.
• Remote Monitoring: Integrated telematics system allows real-time performance tracking, predictive maintenance, and remote diagnostics.

Why Choose ZT10?

The ZT10 Integrated DTH Drill Rig represents the perfect balance of power, precision, and productivity for modern open pit operations. With its robust design, advanced control systems, and comprehensive safety features, it empowers operators to achieve higher drilling rates, consistent hole quality, and lower operating costs. Whether you are expanding a mine, developing a quarry, or executing a large infrastructure project, the ZT10 delivers the performance and reliability you need to succeed.
